Dynamic load management
for electric cars

CLEMAP Load Management handles the real-time load management of wallboxes and charging stations for electric vehicles.

It is the simplest and most reliable load management solution that can be easily and seamlessly integrated into the charging infrastructure for electric cars.

Your advantages

  • Manufacturer-independent
    Compatible with wallboxes and charging stations from different manufacturers
  • Flexibly expandable
    Integration of any number of charging stations, also retrofitted
  • Cost-efficient
    One-off, low investment costs for measurement and operation
  • Fast commissioning
    Installation and activation within a few hours
  • Remote monitoring and control
    Convenient setting option from the "office" or on the road

Your contact

Festim Zeneli
festim@clemap.ch+41 76 544 67 40
Book initial consultation

CLEMAP Load Management consists of two components:

CLEMAP Energy Monitor

Measuring device with local control function

A 3-phase electrical sensor and with three current transformers (or Rogowski coils). There are different versions depending on the connected load.

Order number
Product designation
C-04A-WL-XXXA-XX
CLEMAP Load Management gateway
C-04A-WL-XXXA-ST
CLEMAP Load Management static
C-04A-L-080A-CS
CLEMAP Load Management 80A
C-04A-L-125A-CS
CLEMAP Load Management 125A*
C-04A-L-200A-CS
CLEMAP Load Management 200A*
C-04A-L-400A-CS
CLEMAP Load Management 400A
C-04A-L-01kA-CS
CLEMAP Load Management 1000A
C-04A-L-02kA-CS
CLEMAP Load Management 2000A
C-04A-L-06kA-CS
CLEMAP Load Management 6000A

* Standard versions

CLEMAP Floem for dynamic load management

Software for remote control and billing

Via CLEMAP Floem, charging stations can be added and put into operation with little prior knowledge.

The most important functions are included free of charge as standard with the "FREE" licence. Further functions such as remote monitoring and billing are available with a chargeable licence.

Learn more about the licences
From CHF 998.00 excl. VAT, plus one-off activation costs of CHF 29 from 6 charging stations.From EUR 1,057.90 excl. VAT, plus one-off activation costs of EUR 31 from 6 charging stations.

" WithCLEMAP , we were able to expand our charging infrastructure without increasing the grid connection capacity. The system runs reliably, scales with our growth - and saves costs on an ongoing basis. "

Head of Technology, CHR Cavegn AG

Compatible charging stations

Manufacturer
Model
Communication
Invoicing possible
ABB
ABB Terra AC (6AGC 081281)
Modbus TCP
Invoicing
On request
ABB
ABB Terra AC (6AGC 081285)
Modbus TCP
Invoicing
On request
ABB
ABB Terra AC (6AGC 105897)
Modbus TCP
Invoicing
On request
ABB
ABB Terra AC (6AGC 105901)
Modbus TCP
Invoicing
On request
ABB
ABB Terra DC (all models)
OCPP
Invoicing
On request
ALPITRONIC
Hypercharger
Modbus TCP
Invoicing
On request
Alfen
NG9xx
Modbus TCP
Invoicing
On request
ChargeAmps
Aura
Cloud API (ChargeAmps)
Invoicing
On request
ChargeAmps
Dawn
Cloud API (ChargeAmps)
Invoicing
On request
ChargeAmps
Halo
Cloud API (ChargeAmps)
Invoicing
On request
Circontrol
eNext
Local API
Invoicing
On request
Compleo
CITO 500
Modbus TCP
Invoicing
On request
Compleo
DUO
Modbus TCP
Invoicing
On request
Compleo
eBox Professional
Modbus TCP
Invoicing
On request
Daze
Dazebox Home
Modbus TCP
Invoicing
On request
Daze
Dazebox Share
Modbus TCP
Invoicing
On request
EATON
Green Motion
Modbus TCP
Invoicing
On request
ETREL
Inch
Modbus TCP
Invoicing
On request
EVTEC
bricco&charge
Modbus TCP
Invoicing
On request
EVTEC
caffé corretto system
Modbus TCP
Invoicing
On request
EVTEC
cappuchino&charge
Modbus TCP
Invoicing
On request
EVTEC
crema&charge
Modbus TCP
Invoicing
On request
EVTEC
espresso&charge
Modbus TCP
Invoicing
On request
EVTEC
espresso&charge
Modbus TCP
Invoicing
On request
EVTEC
moka&charge
Modbus TCP
Invoicing
On request
EVTEC
ristretto&charge
Modbus TCP
Invoicing
On request
Easee
Easee Charge
Cloud API (easee Cloud)
Invoicing
On request
Easee
Easee Charge Core
Cloud API (easee Cloud)
Invoicing
On request
Easee
Easee Charge Lite
Cloud API (easee Cloud)
Invoicing
On request
Easee
Easee Charge Up
Cloud API (easee Cloud)
Invoicing
On request
Easee
Easee Home
Cloud API (easee Cloud)
Invoicing
On request
Eve Double Pro-Line
Alfen
Modbus TCP
Invoicing
On request
Hager
witty share
OCPP
Invoicing
On request
Juice
Charge Me
Modbus TCP
Invoicing
On request
KEBA
KEBA KeContact P30c-series
Modbus TCP
Invoicing
On request
KEBA
KEBA KeContact P30x-series
Modbus TCP
Invoicing
On request
Kempower
All DC models
Cloud API
Invoicing
On request
Kostad
Unity 120
Modbus TCP
Invoicing
On request
Kostad
Unity 150
Modbus TCP
Invoicing
On request
Kostad
Unity 180
Modbus TCP
Invoicing
On request
Kostad
Unity 300
Modbus TCP
Invoicing
On request
Kostad
Unity 360
Modbus TCP
Invoicing
On request
Kostad
Unity 50
Modbus TCP
Invoicing
On request
Kostad
Unity 60
Modbus TCP
Invoicing
On request
Kostad
Unity 90
Modbus TCP
Invoicing
On request
MENNEKES
AMEDIO
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON 4Business 710
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON 4Business 730
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON 4Business 760
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON 4Business 780
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON 4You 510
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON 4You 560
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON Premium
Modbus TCP
Invoicing
On request
MENNEKES
AMTRON Professional
Modbus TCP
Invoicing
On request
RAEDIAN
NEX
Modbus TCP
Invoicing
On request
RAEDIAN
NEO
Modbus TCP
Invoicing
On request
SIEMENS
SAFETY
Modbus TCP
Invoicing
On request
SchneiderElectric
Evlink Pro AC
Modbus TCP
Invoicing
On request
Smart-Me
Pico
Cloud API (Smart-Me Cloud)
Invoicing
On request
Sungrow
IDC180E
Modbus TCP
Invoicing
On request
Sungrow
IDC30E
Modbus TCP
Invoicing
On request
Sungrow
IDC480E
Modbus TCP
Invoicing
On request
TECHNIVOLT
TECHNIVOLT 1100
Modbus TCP
Invoicing
On request
TECHNIVOLT
TECHNIVOLT 1100 SMART
Modbus TCP
Invoicing
On request
TECHNIVOLT
TECHNIVOLT 2200 SMART
Modbus TCP
Invoicing
On request
Webasto
Webasto Live
Modbus TCP
Invoicing
On request
Webasto
Webasto Next
Modbus TCP
Invoicing
On request
Webasto
Webasto Unite
Modbus TCP
Invoicing
On request
Weidmüller
Weidmüller Business
Modbus TCP
Invoicing
On request
Weidmüller
Weidmüller Smart Value
Modbus TCP
Invoicing
On request
Zaptec
Zaptec Go
Cloud API (Zaptec Cloud)
Invoicing
On request
Zaptec
Zaptec Pro
Cloud API (Zaptec Cloud)
Invoicing
On request
No compatible charging stations found.

Functions

  • Set-up and commissioning of the load management
  • Operational functionality of local control of any number of charging stations
  • Functionality monitoring via internet with web portal
  • Manual settlement for property management companies
  • Automatic billing for property management companies
  • Prioritisation of the charging stations
  • Optimisation of self-consumption for properties with photovoltaic systems

Available soon

  • Shift load control for phases and load balancing with charging stations which enable the function

Further information

Installation requirements
  • Smartphone or laptop to activate the CLEMAP product
  • enough space in fuse box
  • Ideally an existing network connection with Ethernet cable
    or a WLAN network
Installation

CLEMAP Load Management is installed in a fuse box and must be connected to the power supply lines between the meter and the building.

Installation diagram of CLEMAP Load Management in an underground parking garage
Help Centerdownloads
Activation
  • The meter is connected to the Internet via a WLAN or Ethernet cable connection (see installation instructions).
  • Then the CLEMAP Load Management is activated by means of the information enclosed with the product.
  • After activation, CLEMAP Load Management can be accessed via the CLEMAP Floem portal
Integration and control of the charging stations

The charging stations can be configured via the CLEMAP Floem portal under the menu item Load Management Setup.

Load management setup in CLEMAP Floem
Control function

The available charging power per phase can be set locally or via remote control in the Floem portal.

Integration of ripple control signal from RU

CLEMAP Load Management supports external control signals, e.g. from the utility...

  • via digital input (24VDC).
  • via the cloud using the RestAPI interface.

Supported modes are normal, reduced and locked.

Settlement

Cost-efficient billing is provided by CLEMAP Floem with the
Pro or Unlimited licence, see Licences.

Licences

CLEMAP Floem can be ordered on a licence basis.
(subject to change)

FREE
BASIC
PRO
FLEX
Number of charging stations per CLEMAP device
up to 5
unrestricted
unrestricted
unrestricted
General functionalities
Floem Dashboard Access (Online Portal)
Location, status and remote monitoring of the measuring point
Access to consumption data and visualisation
Download CSV files
Create PDF report
Remote control of relays
Access via Rest API
Set energy tariff
Long-term data storage (> 1 year)
Load management Electric charging stations
Local and remote setup and monitoring of load management
Control via multiple circuits
Cascading of CLEMAP Load Management
1
1
1
DC charging station control
Automatic monthly billing email for property management
2
2
Prioritization of charging stations
Self-consumption optimization (connection of PV systems) or control of external EMSs
2

1 Activation costs of CHF 950 per cascading level
2Applies only to supported metering systems and charging stations

Price
From CHF 998.00 excl. VAT, plus one-off activation costs of CHF 29 from 6 charging stations. The price includes meter and load management.From EUR 1,057.90 excl. VAT, plus one-off activation costs of EUR 31 from 6 charging stations. The price includes meter and load management.
Detailed prices on request

Order standard version

You can order the CLEMAP Load Management 125A, 200A, 400A and 1000A from our sales partner Otto Fischer from our sales partner Otto Fischer.

Order now

Request individual solution

For CLEMAP Load Management 80A, 2000A and 6000A or standard versions with customized cable lengths of the current transformers (or Rogowski coils), please contact us directly at order@clemap.ch
